Switch Power Supply



Gambling Game Machine WEI-YA Switch Power Supply

Gambling Game Machine WEI-YA Switch Power Supply



P02 series is a traditional design switching power supply
which provided two-three output with maximum 50watt.



    ⇒ two-three output
    ⇒ 50watt output power
    ⇒ Low ripple at full loading(less than 50mV)
    ⇒ Over voltage protection
    ⇒ Over current protection
    ⇒ Low ripple noise
    ⇒ Low temperature



Model Number P02BSR3
Weight About 440g
Size 15 cm*11 cm*4 cm(length*width*high)
AC input 95~260 VAC
DC output1 +5V/8A(10MAX)
DC output2 +12V/2.5A(MAX)
SSR output same AC input(6A)
